Fast Paper
FLD-HB77Color options: red, white, gray and black are available.
Thickness range: 0.25-2.4mm
Mechanical properties: excellent mechanical strength, high strength and good toughness, not easy to tear, stronger in the longitudinal direction than in the transverse direction, large elongation in the transverse direction, easy to bend
Electrical properties: excellent electrical insulation performance, anti-static performance, reliable insulation
Heat resistance: heat resistance is divided into A type, heat resistance (electrical safety method 40,000 hours) 105℃, heat resistance (JIS K 6911) 190℃ (2 hours)
Arc resistance: arc resistance 120-140 seconds
Tracking resistance: tracking resistance (UL746A) above 600V
